Swan Neck Wing for MK7 Golf Models (MK7 / MK7.5 GTI & Golf R)
Swan Neck Wing for MK7 Golf Models (MK7 / MK7.5 GTI & Golf R)
This product cannot be returned.
Couldn't load pickup availability
Our swan neck wing utilizes a 55" aluminum foil supported by two billet 6061 aluminum uprights. It weighs in at less than 18lbs when powder coated, and provides significant downforce relative to its span (See the chart for details). With multiple angle of attack positions built into our AOA mounts, you have adjustment to dial in the balance of your car. We include a suggested starting position to maximize downforce and minimize drag penalty.
Our brackets mount under the spoiler cap, near the main hatch pins to improve strength compared to other options on the market. Additionally we provide nut plates, with preinstalled, pneumatically set hex shank rivnuts. All you need to do is drill holes for install, no riv-nut tool required! We retain the OEM 3rd brake light, and the rear wiper is still functional also. The endplates are attached with bolts, and can be swapped to carbon or aftermarket options to further improve this wings performance.
Once installed, the wing can be removed and reinstalled in less than 5 minutes by pulling 4 bolts between the upright and hatch bracket (spoiler cap stays in place). The hatch brackets remain on the car, and the uprights will stay attached to the foil. This offers flexibility to daily your car, and install the wing for events only.
Check out our overview video: https://youtu.be/M6o2VCYS7VA
Kit Contents:
- 1 - 55" aluminum airfoil
- 2 - aluminum endplates
- 2 - billet uprights
- 4 - mounting bracket sets for hatch
- 4 - nut plates for hatch brackets
- Black hardware
- 2 - billet AOA mounts (preinstalled on foil)
- Drilling guide for hatch upper mount (3d printed)
- Paper cut template for spoiler cap slots
Install:https://www.cjminstall.com/volkswagen/MK7G-SN-wing
- Requires cutting slots in the spoiler cap.
- Requires drilling holes in the hatch below window.
- Requires drilling holes in the hatch under the spoiler cap.
- This product uses the same 55" wide aluminum airfoil as the Yeti V2 wing.
- Made to order with a 3-4 week lead time.
- This product cannot be returned or refunded.
Are you interested in just a set of brackets and uprights? We can also make these to your spec to fit other wing foils. Email: support@cjmind.com to inquire.
